VISHAYDatasheet (PDF)
1.5KE47A-E3/54
64.8VC Clamp 23.1A@10/1000us Ipp TVS DIODE DO-27
DO-27ROHS3 CompliantActive
TVS DIODE 40.2VWM 64.8VC DO-27
- Manufacturer
- VISHAY
- Manufacturer part #
- 1.5KE47A-E3/54
- Store part #
- C1973322
- Package / case
- DO-27
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
762 in stock
#C1973322
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹66.12 | ₹66.12 |
| 10+ | ₹58.40 | ₹584.00 |
| 30+ | ₹54.32 | ₹1,629.60 |
| 100+ | ₹50.46 | ₹5,046.00 |
| 500+ | ₹48.30 | ₹24,150.00 |
| 1,400+ | ₹47.02 | ₹65,828.00 |
1 × ₹66.12
₹66.12
excl. GST
₹78.02 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,400 per reel
1.5KE47A-E3/54
₹66.12 for 1 + GST
Specifications
- Clamping Voltage
- 64.8V
- Operating Temperature
- -55℃~+175℃
- Peak Pulse Current (Ipp)
- 23.1A@10/1000us
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 49.4V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 40.2V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,400 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.17 g
