AC33M3064TLBN-01
ARM Cortex-M3 32 Bit 75MHz LQFP-32(7x7) Microcontrollers
LQFP-32(7x7)RoHSActive
32-bit Cortex-M3 based Programmable Motor Controller
- Manufacturer
- ABOV
- Manufacturer part #
- AC33M3064TLBN-01
- Store part #
- C3041475
- Package / case
- LQFP-32(7x7)
- Category
- Microcontrollers
- Packaging
- Box-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,239 in stock
#C3041475
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹130.12 | ₹130.12 |
| 10+ | ₹117.72 | ₹1,177.20 |
| 30+ | ₹110.91 | ₹3,327.30 |
| 100+ | ₹98.31 | ₹9,831.00 |
| 500+ | ₹94.81 | ₹47,405.00 |
| 1,000+ | ₹93.15 | ₹93,150.00 |
1 × ₹130.12
₹130.12
excl. GST
₹153.54 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per box
AC33M3064TLBN-01
₹130.12 for 1 + GST
Specifications
- ADC (Bit)
- 12bit
- Number of I/O
- 28
- Operating Temperature
- -40℃~+105℃
- Voltage - Supply
- 3V~5.5V
- Program Memory Type
- FLASH
- Program Storage Size
- 4KB
- CPU Core
- ARM Cortex-M3
- Core Size
- 32 Bit
- CPU Maximum Speed
- 75MHz
- Oscillator Type
- Built-in+External
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Box-packed
- Standard pack
- 2,500 / Box
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.14 g
Overview
Key features
- Maximum operating frequency: 48MHz 32-bit ARM Cortex-M3
- 64KB code flash memory
- 8KB SRAM
- Two main operating clocks: HCLK, PCLK
- Two system reset: cold reset, warm reset
- Power management mode: Run mode, Sleep mode
- Nested Vector Interrupt Controller (NVIC)
- Watchdog Timer
- Six general purpose timers
- Periodic, one-shot, PWM, capture mode
- 2 UARTs, 1 I2C, 1 SPI
- MPWM generators
- 1.5Msps ADC
- 2 units with 11 channel Inputs
- SWD debug interface
- JTAG Debugger (JTAG is only for LQFP-48)
- Four types of package options: LQFP48-0707 (0.5mm pitch), LQFP32-0707 (0.8mm pitch)
- Operating voltage: 3.0V to 5.5V
