AOD409-VB
P-Channel 60V 50A Surface Mount TO-252
TO-252RoHSActive
MOSFET P-CH 60V 50A TO-252
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- AOD409-VB
- Store part #
- C5382702
- Package / case
- TO-252
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
35 in stock
#C5382702
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹140.20 | ₹140.20 |
| 10+ | ₹118.00 | ₹1,180.00 |
| 50+ | ₹85.35 | ₹4,267.50 |
| 100+ | ₹74.23 | ₹7,423.00 |
| 500+ | ₹67.71 | ₹33,855.00 |
| 1,000+ | ₹64.23 | ₹64,230.00 |
1 × ₹140.20
₹140.20
excl. GST
₹165.44 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per reel
AOD409-VB
₹140.20 for 1 + GST
Specifications
- Drain to Source Voltage
- 60V
- Operating Temperature
- -55℃~+150℃
- Output Capacitance(Coss)
- 380pF
- Current - Continuous Drain(Id)
- 50A
- Ciss-Input Capacitance
- 2.95nF
- Reverse Transfer Capacitance (Crss)
- 305pF
- RDS(on)
- 20mΩ@10V;25mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 110nC@10V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 50 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.364 g
Overview
Applications
- Load Switch
Key features
- Trench Power MOSFET
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RJJ0606JPD-VB#C18212486VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 9 | ₹110.07 · 9 in stock | View |
 | AUFR5305-VB#C19190133VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 39 | ₹96.92 · 39 in stock | View |
 | SSD50P06-15D-VB#C19190291VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 37 | ₹115.83 · 37 in stock | View |
 | CEU5175-VB#C19711316VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 35 | ₹115.83 · 35 in stock | View |
 | NP36P06SLG-E1-AY-VB#C19711342VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 65 | ₹115.83 · 65 in stock | View |
