AP3015AKTR-G1
Boost Switching Regulator IC Fixed 3.3V 1 Output 100mA SOT-23-5
SOT-23-5ROHS CompliantActive
Micro Power Step-Up DC-DC Converter
- Manufacturer
- DIODES
- Manufacturer part #
- AP3015AKTR-G1
- Store part #
- C154879
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
28,903 in stock
#C154879
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹60.94 | ₹60.94 |
| 10+ | ₹48.36 | ₹483.60 |
| 30+ | ₹42.93 | ₹1,287.90 |
| 100+ | ₹36.21 | ₹3,621.00 |
| 500+ | ₹33.39 | ₹16,695.00 |
| 1,000+ | ₹26.90 | ₹26,900.00 |
1 × ₹60.94
₹60.94
excl. GST
₹71.91 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
AP3015AKTR-G1
₹60.94 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Function
- Boost
- Number of Outputs
- 1
- Features
- Overcurrent Protection
- Output Type
- Fixed
- Topology
- Boost
- Operating Voltage
- 1V~12V
- Switch tube (built-in/external)
- Built-in
- Output Voltage
- 3.3V
- Output Current
- 100mA
- Quiescent Current
- 17uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.2 g
Overview
The AP3015/A are Pulse Frequency Modulation (PFM) DC/DC converters. These two devices are functionally equivalent except the switching current limit. The AP3015 is designed for higher power systems with 350mA current limit, and the AP3015A is for lower power systems with 100mA current limit.
Applications
- MP3, MP4
- Battery Power Supply System
- LCD/OLED Bias Supply
- Handheld Device
- Portable Communication Device
Key features
- The AP3015/A feature a wide input voltage. The operation voltage is ranged from 1.2V to 12V (1V to 12V for AP3015A).
- A current limited, fixed off - time control scheme conserves operating current, resulting in high efficiency over a broad range of load current.
- They also feature low quiescent current, switching current limiting, low temperature coefficient, etc.
- Fewer tiny external components are required in the applications to save space and lower cost.
- A disable terminal is designed to turn on or turn off the chip.
- The AP3015/A are available in SOT - 23 - 5 package.
- Low Quiescent Current: In Active Mode (Not Switching): 17μA Typical; In Shutdown Mode: <1μA
- Low Operating ΔVN: 1.2V Typical for AP3015; 1.0V Typical for AP3015A
- Low VCESAT Switch: 200mV Typical at 300mA for AP3015; 70mV Typical at 70mA for AP3015A
- High Output Voltage: up to 34V
- Fixed Off - Time Control
- Switching Current Limiting: 350mA Typical for AP3015; 100mA Typical for AP3015A
- Operating Temperature Range: - 40℃ to 85℃
