Wuxi Chipown Micro-electronics

APS2415TBER-ADJ

Buck Switching Regulator IC Adjustable 1 Output 1.5A SOT-23-5L

SOT-23-5LROHS CompliantActive

1.5MHz, 1.5A Synchronous Buck Regulator

Manufacturer: Wuxi Chipown Micro-electronics
Manufacturer part #: APS2415TBER-ADJ
Store part #: C130330
Package / case: SOT-23-5L
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,710 in stock

#C130330

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
5+	₹13.43	₹67.15
50+	₹10.62	₹531.00
150+	₹9.21	₹1,381.50
500+	₹8.15	₹4,075.00
3,000+	₹7.32	₹21,960.00
6,000+	₹6.89	₹41,340.00

Quantity (min 5, multiples of 5)

5 × ₹13.43

₹67.15

excl. GST

₹79.24 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

APS2415TBER-ADJ

₹67.15 for 5 + GST

Specifications

Operating Temperature: -40℃~+85℃@(TA)
Frequency - Switching: 1.5MHz
Function: Step-down type
Number of Outputs: 1
Features: Cycle-by-cycle current limiting;Light load efficient mode;Overcurrent Protection
Output Type: Adjustable
Topology: Buck
Operating Voltage: 2.5V~6.5V
Switch tube (built-in/external): Built-in
Output Current: 1.5A
Quiescent Current: 300uA

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.04 g

Overview

APS2415 is a high-efficiency, 1.5MHz fixed-frequency, current-mode monolithic synchronous buck regulator. Available in adjustable and fixed output versions, the regulator operates at 300μA quiescent current under no-load conditions, dropping below 1μA in shutdown. The input voltage range of 2.5V to 6.5V makes the APS2415 ideal for single-cell Li-ion battery or 2- to 4-cell alkaline battery-powered applications. The APS2415 achieves low dropout operation via 100% duty cycle, extending battery life in portable devices. At light loads, the APS2415 enters pulse-skip mode to maintain low output ripple voltage, making it suitable for noise-sensitive applications. The 1.5MHz switching frequency allows the use of smaller SMT inductors and capacitors. An integrated synchronous rectifier switch improves efficiency, eliminating the need for an external Schottky diode. The feedback voltage is set at 0.6V, enabling output voltages as low as 0.6V. The APS2415 is available in a compact SOT package.

Applications

Mobile phones and smartphones
Microprocessor and DSP core power supply
Wireless and DSL modems
PDAs
Portable media players
Digital cameras and camcorders
Various handheld devices

Key features

High efficiency: up to 96%
1.5MHz constant switching frequency
1.5A output current (VIN = 3.6V & Vout = 1.8V)
Integrated power switch and synchronous rectifier switch, no external Schottky diode required
2.5V to 6.5V input voltage range
Output voltage as low as 0.6V
Low dropout operation: duty cycle up to 100%
Low quiescent current: 300uA (ΔVIN < 4.2V)
Current mode control for excellent line and load transient response
Short-circuit protection and over-temperature protection
Standby current less than 1uA
Soft-start
Space-saving 5-pin SOT23 package
