AZ432ANTR-TP
1.25V~18V ±0.5% 100mA Adjustable SOT-23 Voltage Reference
SOT-23RoHSActive
Precision adjustable reference source
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- AZ432ANTR-TP
- Store part #
- C47117520
- Package / case
- SOT-23
- Category
- Voltage Reference
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,520 in stock
#C47117520
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.00 | ₹80.00 |
| 100+ | ₹6.28 | ₹628.00 |
| 300+ | ₹5.44 | ₹1,632.00 |
| 3,000+ | ₹4.79 | ₹14,370.00 |
| 6,000+ | ₹4.27 | ₹25,620.00 |
| 9,000+ | ₹4.01 | ₹36,090.00 |
10 × ₹8.00
₹80.00
excl. GST
₹94.40 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
AZ432ANTR-TP
₹80.00 for 10 + GST
Specifications
- Quiescent Current
- 35uA
- Output Voltage
- 1.25V~18V
- Tolerance
- ±0.5%
- Minimum Cathode Current for Regulation
- 100uA
- Reference Type
- Parallel
- Output Current
- 100mA
- Operating Temperature
- -25℃~+125℃
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.032 g
Overview
AZ432ANTR-TP is a three terminal adjustable parallel regulator that can Set the output voltage through two external resistors Between Vref (approximately 1.25V) and 18V Any value. Active output circuits can provide very sharp The conductivity characteristics of these devices enable them to be used in many applications Becoming an excellent substitute for Zener diodes in use, this Some applications include onboard voltage regulation, adjustable power supply, and power on/off Power off.
Applications
- Adjustable voltage and current reference
- Zener diode replacement products
- Voltage monitoring
- A comparator with an integrated benchmark
- Precision current limiter
Key features
- Adjustable output voltage range: 1.25V~18
- Stable capacitive load
- Low temperature float 16mV
- Low working current of 35μA (typ)
- Current capacity range 0.1 - 100 mA
- accuracy: B
- Package appearance SOT23
- Low output noise voltage
