B4B-PH-K-S(LF)(SN)
Connector Header 4 position 2mm Pitch 2A Through Hole -25℃~+85℃
PopularThrough Hole,P=2mmROHS CompliantActive
CONN HEADER TH 4POS 2mm
- Manufacturer
- JST
- Manufacturer part #
- B4B-PH-K-S(LF)(SN)
- Store part #
- C131334
- Package / case
- Through Hole,P=2mm
- Category
- Headers, Male Pins
- Packaging
- Box-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
55,720 in stock
#C131334
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹5.04 | ₹50.40 |
| 100+ | ₹4.14 | ₹414.00 |
| 300+ | ₹3.67 | ₹1,101.00 |
| 1,000+ | ₹3.30 | ₹3,300.00 |
| 5,000+ | ₹3.17 | ₹15,850.00 |
| 10,000+ | ₹3.07 | ₹30,700.00 |
10 × ₹5.04
₹50.40
excl. GST
₹59.47 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 1,000 per box
B4B-PH-K-S(LF)(SN)
₹50.40 for 10 + GST
Specifications
- Connector Type
- Through Hole
- Reference Series
- PH
- Voltage Rating (Max)
- 100V
- Contact Material
- Brass
- Number of PINs Per Row
- 4
- Number of Rows
- 1
- Pitch
- 2mm
- Flame Retardant Rating
- UL94V-0
- Current Rating
- 2A
- Supplementary Features
- K Pin
- Operating Temperature
- -25℃~+85℃
- Contact Plating
- Tin
- Number of PINs
- 4P
- Plastic Material
- PA66
- Color
- White
- X-Length of Bottom Edge on Board (Spacing Line)
- 9.9mm
- Pin Structure
- 1x4P
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Box-packed
- Standard pack
- 1,000 / Box
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.238 g
