DIODES

BC857BFZ-7B

Bipolar (BJT) Transistor PNP 45V 100mA 100MHz 925mW Surface Mount X2-DFN0606-3

X2-DFN0606-3ROHS3 CompliantActive

TRANS PNP 45V 100mA X2-DFN0606-3

Manufacturer: DIODES
Manufacturer part #: BC857BFZ-7B
Store part #: C6129194
Package / case: X2-DFN0606-3
Category: Single Bipolar Transistors
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

249 in stock

#C6129194

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹62.35	₹62.35
10+	₹49.93	₹499.30
30+	₹44.48	₹1,334.40
100+	₹37.94	₹3,794.00
500+	₹34.89	₹17,445.00
1,000+	₹33.14	₹33,140.00

Quantity (min 1)

1 × ₹62.35

₹62.35

excl. GST

₹73.57 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 10,000 per reel

BC857BFZ-7B

₹62.35 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -55℃~+150℃
Current - Collector Cutoff: 15nA
Transition frequency(fT): 100MHz
Collector - Emitter Voltage VCEO: 45V
Emitter-Base Voltage VEBO: 6V
DC Current Gain: 200
Current - Collector(Ic): 100mA
Pd - Power Dissipation: 925mW
Number: 1 PNP
type: PNP
Vce Saturation(VCE(sat)): 70mV

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 10,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.048 g

Overview

Key features

BVCEO >-45 V
IC =-100 mA High Collector Current
PD = 925 mW Power Dissipation
0.36 mm² Package Footprint, 40% Smaller than DFN1006
0.4mm Height Package Minimizing Off-Board Profile
Complementary NPN Type BC847BFZ
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. "Green" Device
