BD681G
100V 750 4A NPN TO-225-3 Single Bipolar Transistors RoHS
TO-225-3ROHS3 CompliantActive
- Manufacturer
- onsemi
- Manufacturer part #
- BD681G
- Store part #
- C38376
- Package / case
- TO-225-3
- Category
- Single Bipolar Transistors
- Packaging
- Box-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
212 in stock
#C38376
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹114.62 | ₹114.62 |
| 10+ | ₹96.42 | ₹964.20 |
| 30+ | ₹87.33 | ₹2,619.90 |
| 100+ | ₹78.44 | ₹7,844.00 |
| 500+ | ₹73.03 | ₹36,515.00 |
| 1,000+ | ₹70.21 | ₹70,210.00 |
1 × ₹114.62
₹114.62
excl. GST
₹135.25 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 500 per box
BD681G
₹114.62 for 1 + GST
Specifications
- Current - Collector Cutoff
- 200uA
- Operating Temperature
- -55℃~+150℃@(Tj)
- Vbe On(VBE(on))
- 2.5V
- Collector - Emitter Voltage VCEO
- 100V
- Emitter-Base Voltage VEBO
- 5V
- DC Current Gain
- 750
- Pd - Power Dissipation
- 40W
- Current - Collector(Ic)
- 4A
- type
- NPN
- Vce Saturation(VCE(sat))
- 2.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Box-packed
- Standard pack
- 500 / Box
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.774 g
Overview
This series of plastic-packaged, medium-power silicon NPN Darlington transistors can be used as output devices in complementary general-purpose amplifier applications.
Key features
- High DC current gain
- Monolithic construction
- Complementary to BD676, 676A, 678, 678A, 680, 680A, 682
- BD677, 677A, 679, 679A equivalent to MJE 800, 801, 802, 803
- These devices are lead-free and RoHS compliant*
