NexperiaDatasheet (PDF)
BZA408B,115
nan
SOT-457ROHS3 CompliantActive
ESD DIODE 5VWM SOT-457
- Manufacturer
- Nexperia
- Manufacturer part #
- BZA408B,115
- Store part #
- C550053
- Package / case
- SOT-457
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,225 in stock
#C550053
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹76.43 | ₹76.43 |
| 10+ | ₹60.88 | ₹608.80 |
| 30+ | ₹52.89 | ₹1,586.70 |
| 100+ | ₹45.13 | ₹4,513.00 |
| 500+ | ₹40.59 | ₹20,295.00 |
| 1,000+ | ₹38.22 | ₹38,220.00 |
1 × ₹76.43
₹76.43
excl. GST
₹90.19 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
BZA408B,115
₹76.43 for 1 + GST
Specifications
- Operating Temperature
- -65℃~+150℃
- Peak Pulse Power Dissipation (Ppp)
- 20W
- Number of Channels
- Four channels
- type
- ESD
- Reverse Leakage Current (Ir)
- 100nA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.029 g
Overview
4-bit wide monolithic bidirectional ESD transient voltage suppressor in a six lead SOT457 (SC - 74) package.
Applications
- Protection of equipment, connected to data and transmission lines, against voltage surges caused by electrostatic discharge e.g:
- Computers and peripherals
- Audio and video equipment
- Communication systems
- Medical equipment
- Portable electronics
Key features
- ESD rating >15 kV according to IEC1000 - 4 - 2
- SOT457 surface mount package
- Non - clamping range: - 5 V to +5 V
- Channel separation: >70 dB
- Low reverse current: < 100 nA
- Low diode capacitance: < 75 pF
