VISHAYDatasheet (PDF)
BZG05C12-M3-08
1 Independent 11.4V~12.7V 12V DO-214AC Single Zener Diodes RoHS
DO-214ACROHS3 CompliantActive
- Manufacturer
- VISHAY
- Manufacturer part #
- BZG05C12-M3-08
- Store part #
- C3018886
- Package / case
- DO-214AC
- Category
- Single Zener Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
748 in stock
#C3018886
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹73.36 | ₹73.36 |
| 10+ | ₹59.91 | ₹599.10 |
| 30+ | ₹54.04 | ₹1,621.20 |
| 100+ | ₹46.89 | ₹4,689.00 |
| 500+ | ₹43.84 | ₹21,920.00 |
| 1,500+ | ₹41.89 | ₹62,835.00 |
1 × ₹73.36
₹73.36
excl. GST
₹86.56 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
BZG05C12-M3-08
₹73.36 for 1 + GST
Specifications
- Diode Configuration
- 1 Independent
- Pd - Power Dissipation
- 1.25W
- Reverse Leakage Current (Ir)
- 500nA@9.1V
- Impedance(Zzt)
- 9Ω
- Zener Voltage(Range)
- 11.4V~12.7V
- Zener Voltage(Nom)
- 12V
- Impedance(Zzk)
- 350Ω
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.325 g
Overview
Applications
- Voltage stabilization
Key features
- High reliability
- Voltage range 3.3 V to 100 V
- Fits onto 5 mm SMD footpads
- Wave and reflow solderable
- AEC-Q101 qualified available
- halogen-free, RoHS-compliant, and commercial grade
- halogen-free, RoHS-compliant, and AEC-Q101 qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SMAZ12-TP#C49274890TECH PUBLIC · SMA | TECH PUBLIC | SMA | 1,770 | ₹7.96 · 1,770 in stock | View |
 | BZG03C12#C7432406YONGYUTAI · SMA | YONGYUTAI | SMA | 1,170 | ₹10.00 · 1,170 in stock | View |
 | SMA4742A#C2917849ZHIDE · SMA | ZHIDE | SMA | 5,730 | ₹7.92 · 5,730 in stock | View |
 | 1SMA1A12#C18199568BORN · SMA | BORN | SMA | 9,220 | ₹5.41 · 9,220 in stock | View |
 | 1SMA4742A#C173481MDD(Microdiode Semiconductor) · SMA(DO-214AC) | MDD(Microdiode Semiconductor) | SMA(DO-214AC) | 69,500 | ₹7.09 · 69,500 in stock | View |
