NexperiaDatasheet (PDF)
BZX79-C2V4,133
1 Independent 2.2V~2.6V 2.4V SOD27(DO-35) Single Zener Diodes RoHS
SOD27(DO-35)ROHS3 CompliantActive
- Manufacturer
- Nexperia
- Manufacturer part #
- BZX79-C2V4,133
- Store part #
- C550816
- Package / case
- SOD27(DO-35)
- Category
- Single Zener Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
345 in stock
#C550816
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹11.36 | ₹56.80 |
| 50+ | ₹11.09 | ₹554.50 |
| 150+ | ₹10.90 | ₹1,635.00 |
| 500+ | ₹10.72 | ₹5,360.00 |
5 × ₹11.36
₹56.80
excl. GST
₹67.02 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
BZX79-C2V4,133
₹56.80 for 5 + GST
Specifications
- Diode Configuration
- 1 Independent
- Tolerance
- ±5%
- Operating Junction Temperature Range
- -65℃~+200℃
- Pd - Power Dissipation
- 400mW
- Reverse Leakage Current (Ir)
- 50uA@1V
- Impedance(Zzt)
- 100Ω
- Zener Voltage(Range)
- 2.2V~2.6V
- Zener Voltage(Nom)
- 2.4V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.139 g
Overview
Low-power voltage regulator diodes in hermetically sealed leaded glass SOD27 (DO-35) packages. The diodes are available in the normalized E24 ±2% (BZX79-B) and approx. ±5% (BZX79-C) tolerance range. The series consists of 37 types with nominal working voltages from 2.4 to 75 V.
Applications
- Low voltage stabilizers or voltage references.
Key features
- Total power dissipation: max. 500 mW
- Two tolerance series: ±2%, and approx. ±5%
- Working voltage range: nom. 2.4 to 75 V (E24 range)
- Non-repetitive peak reverse power dissipation: max. 40 W
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| BZX79C2V4#C895314onsemi · DO-35 | onsemi | DO-35 | 1,195 | ₹14.09 · 1,195 in stock | View | |
 | 1N5221B#C5157520LGE · DO-35 | LGE | DO-35 | 10,220 | ₹3.29 · 10,220 in stock | View |
 | BZX55C2V4PF#C19190378ST(Semtech) · DO-35 | ST(Semtech) | DO-35 | 350 | ₹2.55 · 350 in stock | View |
 | BZX55C2V4#C5190025LGE · DO-35 | LGE | DO-35 | 2,020 | ₹2.74 · 2,020 in stock | View |
 | 1N5222BPF#C19271495ST(Semtech) · DO-35 | ST(Semtech) | DO-35 | 260 | ₹3.31 · 260 in stock | View |
