WALSONDatasheet (PDF)
C42P233434P40001
330nF ±10% X2 Through Hole,P=10mm Ceramic Capacitors
Through Hole,P=10mmRoHSActive
- Manufacturer
- WALSON
- Manufacturer part #
- C42P233434P40001
- Store part #
- C53670912
- Package / case
- Through Hole,P=10mm
- Category
- Ceramic Capacitors
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
290 in stock
#C53670912
Stock & price checked 31 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.72 | ₹87.20 |
| 100+ | ₹7.08 | ₹708.00 |
| 500+ | ₹6.26 | ₹3,130.00 |
| 1,000+ | ₹5.64 | ₹5,640.00 |
| 5,000+ | ₹5.13 | ₹25,650.00 |
| 10,000+ | ₹4.90 | ₹49,000.00 |
10 × ₹8.72
₹87.20
excl. GST
₹102.90 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 500 per bag
C42P233434P40001
₹87.20 for 10 + GST
Specifications
- Capacitance
- 330nF
- Tolerance
- ±10%
- Operating Temperature
- -40℃~+110℃
- Ratings
- X2
- Voltage(AC)
- 275V;310V
- safety certification
- UL;VDE;CQC;KC;ENEC
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Bag-packed
- Standard pack
- 500 / Bag
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 1 g
Overview
This product is wound from metallized high-temperature polypropylene film, with lead-free metal sprayed on the end faces and leads soldered, encapsulated externally in a flame-retardant plastic case and flame-retardant epoxy resin.
Applications
- For anti-interference applications such as power line crossing
Key features
- Metallized polypropylene film dielectric
- Withstands overvoltage surges
- Excellent flame retardancy
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | C42Q333446P40001#C46638868WALSON · Through Hole,P=10mm | WALSON | Through Hole,P=10mm | 8,800 | ₹6.76 · 8,800 in stock | View |
