WALSONDatasheet (PDF)
C42Q310546P60001
1uF ±10% X2 Through Hole,P=15mm Ceramic Capacitors
Through Hole,P=15mmRoHSActive
- Manufacturer
- WALSON
- Manufacturer part #
- C42Q310546P60001
- Store part #
- C53670835
- Package / case
- Through Hole,P=15mm
- Category
- Ceramic Capacitors
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
885 in stock
#C53670835
Stock & price checked 36 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹24.08 | ₹120.40 |
| 50+ | ₹19.42 | ₹971.00 |
| 150+ | ₹17.42 | ₹2,613.00 |
| 500+ | ₹14.94 | ₹7,470.00 |
| 2,500+ | ₹13.83 | ₹34,575.00 |
| 5,000+ | ₹13.15 | ₹65,750.00 |
5 × ₹24.08
₹120.40
excl. GST
₹142.07 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 500 per bag
C42Q310546P60001
₹120.40 for 5 + GST
Specifications
- Capacitance
- 1uF
- Tolerance
- ±10%
- Operating Temperature
- -40℃~+110℃
- Ratings
- X2
- Voltage(AC)
- 275V;310V
- safety certification
- UL;VDE;CQC;ENEC
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Bag-packed
- Standard pack
- 500 / Bag
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 4.673 g
Overview
This product is wound from metallized high-temperature polypropylene film, with lead-free metal sprayed on the end faces and leads soldered, encapsulated externally in a flame-retardant plastic case and flame-retardant epoxy resin.
Applications
- For anti-interference applications such as power line crossing
Key features
- Metallized polypropylene film dielectric
- Withstands overvoltage surges
- Excellent flame retardancy
