WALSONDatasheet (PDF)
C42Q3223A3P40002
22nF ±10% X2 Through Hole,P=10mm Ceramic Capacitors
Through Hole,P=10mmRoHSActive
- Manufacturer
- WALSON
- Manufacturer part #
- C42Q3223A3P40002
- Store part #
- C53670851
- Package / case
- Through Hole,P=10mm
- Category
- Ceramic Capacitors
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,180 in stock
#C53670851
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹5.46 | ₹109.20 |
| 200+ | ₹4.43 | ₹886.00 |
| 500+ | ₹3.92 | ₹1,960.00 |
| 2,000+ | ₹3.53 | ₹7,060.00 |
| 10,000+ | ₹3.21 | ₹32,100.00 |
| 20,000+ | ₹3.07 | ₹61,400.00 |
20 × ₹5.46
₹109.20
excl. GST
₹128.86 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 500 per bag
C42Q3223A3P40002
₹109.20 for 20 + GST
Specifications
- Capacitance
- 22nF
- Tolerance
- ±10%
- Operating Temperature
- -40℃~+110℃
- Ratings
- X2
- Voltage(AC)
- 275V;310V
- safety certification
- UL;VDE;CQC;KC;ENEC
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Bag-packed
- Standard pack
- 500 / Bag
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 1.004 g
Overview
This product is wound from metallized high-temperature polypropylene film, with lead-free metal sprayed on the end faces and leads soldered, encapsulated externally in a flame-retardant plastic case and flame-retardant epoxy resin.
Applications
- For anti-interference applications such as power line crossing
Key features
- Metallized polypropylene film dielectric
- Withstands overvoltage surges
- Excellent flame retardancy
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | C42Q3223A0P40001#C53670850WALSON · Through Hole,P=10mm | WALSON | Through Hole,P=10mm | 2,820 | ₹5.46 · 2,820 in stock | View |
 | C42Q322380P40001#C46638845WALSON · Through Hole,P=10mm | WALSON | Through Hole,P=10mm | On request | ₹5.42 · 0 in stock | View |
