WALSONDatasheet (PDF)
C42Q322438P40002
220nF ±10% X2 Through Hole,P=10mm Ceramic Capacitors
Through Hole,P=10mmRoHSActive
- Manufacturer
- WALSON
- Manufacturer part #
- C42Q322438P40002
- Store part #
- C53670854
- Package / case
- Through Hole,P=10mm
- Category
- Ceramic Capacitors
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,650 in stock
#C53670854
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.45 | ₹84.50 |
| 100+ | ₹6.85 | ₹685.00 |
| 500+ | ₹6.06 | ₹3,030.00 |
| 1,000+ | ₹5.46 | ₹5,460.00 |
| 5,000+ | ₹4.97 | ₹24,850.00 |
| 10,000+ | ₹4.74 | ₹47,400.00 |
10 × ₹8.45
₹84.50
excl. GST
₹99.71 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 500 per bag
C42Q322438P40002
₹84.50 for 10 + GST
Specifications
- Capacitance
- 220nF
- Tolerance
- ±10%
- Operating Temperature
- -40℃~+110℃
- Ratings
- X2
- Voltage(AC)
- 275V;310V
- safety certification
- UL;VDE;CQC;KC;ENEC
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Bag-packed
- Standard pack
- 500 / Bag
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 1 g
Overview
This product is wound from metallized high-temperature polypropylene film, with lead-free metal sprayed on the end faces and leads soldered, encapsulated externally in a flame-retardant plastic case and flame-retardant epoxy resin.
Applications
- For anti-interference applications such as power line crossing
Key features
- Metallized polypropylene film dielectric
- Withstands overvoltage surges
- Excellent flame retardancy
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | C42P222434P40001#C53670853WALSON · Through Hole,P=10mm | WALSON | Through Hole,P=10mm | 4,080 | ₹7.37 · 4,080 in stock | View |
 | C42Q322458P40001#C53670855WALSON · Through Hole,P=10mm | WALSON | Through Hole,P=10mm | 790 | ₹9.54 · 790 in stock | View |
 | C42Q322448P40001#C46638866WALSON · Through Hole,P=10mm | WALSON | Through Hole,P=10mm | 6,910 | ₹7.94 · 6,910 in stock | View |
