WALSONDatasheet (PDF)
C42Q333460P60001
330nF ±10% X2 Through Hole,P=15mm Ceramic Capacitors
Through Hole,P=15mmRoHSActive
- Manufacturer
- WALSON
- Manufacturer part #
- C42Q333460P60001
- Store part #
- C53670915
- Package / case
- Through Hole,P=15mm
- Category
- Ceramic Capacitors
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,925 in stock
#C53670915
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.54 | ₹62.70 |
| 50+ | ₹10.17 | ₹508.50 |
| 150+ | ₹8.98 | ₹1,347.00 |
| 500+ | ₹8.10 | ₹4,050.00 |
| 2,500+ | ₹7.38 | ₹18,450.00 |
| 5,000+ | ₹7.03 | ₹35,150.00 |
5 × ₹12.54
₹62.70
excl. GST
₹73.99 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 500 per bag
C42Q333460P60001
₹62.70 for 5 + GST
Specifications
- Capacitance
- 330nF
- Tolerance
- ±10%
- Operating Temperature
- -40℃~+110℃
- Ratings
- X2
- Voltage(AC)
- 275V;310V
- safety certification
- UL;VDE;CQC;KC;ENEC
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Bag-packed
- Standard pack
- 500 / Bag
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 2.716 g
Overview
This product is wound from metallized high-temperature polypropylene film, with lead-free metal sprayed on the end faces and leads soldered, encapsulated externally in a flame-retardant plastic case and flame-retardant epoxy resin.
Applications
- For anti-interference applications such as power line crossing
Key features
- Metallized polypropylene film dielectric
- Withstands overvoltage surges
- Excellent flame retardancy
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | C42Q333445P60001#C53670914WALSON · Through Hole,P=15mm | WALSON | Through Hole,P=15mm | 2,840 | ₹9.92 · 2,840 in stock | View |
 | C42Q333448P60001#C46638869WALSON · Through Hole,P=15mm | WALSON | Through Hole,P=15mm | 1,960 | ₹11.36 · 1,960 in stock | View |
 | C42Q333470P60001#C53670916WALSON · Through Hole,P=15mm | WALSON | Through Hole,P=15mm | 50 | ₹14.17 · 50 in stock | View |
