WALSONDatasheet (PDF)
C42Q368453P600G1
680nF ±10% X2 Through Hole,P=15mm Ceramic Capacitors
Through Hole,P=15mmRoHSActive
- Manufacturer
- WALSON
- Manufacturer part #
- C42Q368453P600G1
- Store part #
- C53670934
- Package / case
- Through Hole,P=15mm
- Category
- Ceramic Capacitors
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
985 in stock
#C53670934
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹18.85 | ₹94.25 |
| 50+ | ₹15.14 | ₹757.00 |
| 250+ | ₹13.28 | ₹3,320.00 |
| 500+ | ₹11.89 | ₹5,945.00 |
| 2,500+ | ₹10.78 | ₹26,950.00 |
| 5,000+ | ₹10.23 | ₹51,150.00 |
5 × ₹18.85
₹94.25
excl. GST
₹111.21 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 250 per bag
C42Q368453P600G1
₹94.25 for 5 + GST
Specifications
- Capacitance
- 680nF
- Tolerance
- ±10%
- Operating Temperature
- -40℃~+110℃
- Ratings
- X2
- Voltage(AC)
- 275V;310V
- safety certification
- UL;VDE;CQC;ENEC
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Bag-packed
- Standard pack
- 250 / Bag
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 4.677 g
Overview
This product is wound from metallized high-temperature polypropylene film, with lead-free metal sprayed on the end faces and leads soldered, encapsulated externally in a flame-retardant plastic case and flame-retardant epoxy resin.
Applications
- For anti-interference applications such as power line crossing
Key features
- Metallized polypropylene film dielectric
- Withstands overvoltage surges
- Excellent flame retardancy
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | C42Q368438P60001#C53670932WALSON · Through Hole,P=15mm | WALSON | Through Hole,P=15mm | 890 | ₹19.08 · 890 in stock | View |
 | C42Q368443P60001#C53670933WALSON · Through Hole,P=15mm | WALSON | Through Hole,P=15mm | 2,070 | ₹19.10 · 2,070 in stock | View |
 | C42Q368446P60001#C46638878WALSON · Through Hole,P=15mm | WALSON | Through Hole,P=15mm | 2,540 | ₹21.27 · 2,540 in stock | View |
