VBsemi ElecDatasheet (PDF)
CEP93A3-VB
N-Channel 30V 140A 175W Through Hole TO-220AB
TO-220ABRoHSActive
MOSFET N-CH 30V 140A TO-220AB
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- CEP93A3-VB
- Store part #
- C19190263
- Package / case
- TO-220AB
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
18 in stock
#C19190263
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹159.50 | ₹159.50 |
| 10+ | ₹134.51 | ₹1,345.10 |
| 50+ | ₹90.40 | ₹4,520.00 |
| 100+ | ₹78.02 | ₹7,802.00 |
| 500+ | ₹70.62 | ₹35,310.00 |
| 1,000+ | ₹66.93 | ₹66,930.00 |
1 × ₹159.50
₹159.50
excl. GST
₹188.21 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
CEP93A3-VB
₹159.50 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 30V
- Output Capacitance(Coss)
- 1.725nF
- Current - Continuous Drain(Id)
- 140A
- Ciss-Input Capacitance
- 8.4nF
- Pd - Power Dissipation
- 175W
- Reverse Transfer Capacitance (Crss)
- 970pF
- RDS(on)
- 2.8mΩ@4.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 257nC@10V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.2 g
Overview
Applications
- OR-ing
- Server DC/DC
- N-Channel MOSFET
Key features
- DT-Trench Power MOSFET
- 100 % Rg and UIS Tested
- Compliant to RoHS Directive 2011/65/EU
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PSMN1R8-30PL-VB#C19190163VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 20 | ₹131.92 · 20 in stock | View |
 | PSMN1R1-30PL-VB#C29778735VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 10 | ₹123.52 · 10 in stock | View |
 | 125N2RG-VB#C29778744VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 10 | ₹123.52 · 10 in stock | View |
 | MTB1D7N03E3-VB#C3040203VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 46 | ₹131.81 · 46 in stock | View |
 | IRF1324PBF-VB#C22357145VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 10 | ₹125.95 · 10 in stock | View |
