PANASONICDatasheet (PDF)
ECQUAAF154K
150nF ±10% X2 275V Through Hole,P=15mm Ceramic Capacitors RoHS
Through Hole,P=15mmROHS3 CompliantActive
- Manufacturer
- PANASONIC
- Manufacturer part #
- ECQUAAF154K
- Store part #
- C542181
- Package / case
- Through Hole,P=15mm
- Category
- Ceramic Capacitors
- Packaging
- Bag-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
80 in stock
#C542181
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹33.04 | ₹33.04 |
| 10+ | ₹32.22 | ₹322.20 |
| 30+ | ₹31.80 | ₹954.00 |
| 100+ | ₹31.41 | ₹3,141.00 |
1 × ₹33.04
₹33.04
excl. GST
₹38.99 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per bag
ECQUAAF154K
₹33.04 for 1 + GST
Specifications
- Capacitance
- 150nF
- Tolerance
- ±10%
- Operating Temperature
- -40℃~+110℃
- Ratings
- X2
- Voltage(AC)
- 275V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Bag-packed
- Standard pack
- 1,000 / Bag
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 5.07 g
Overview
Metallized Polypropylene Film Capacitors ECQUA Series [Class X2], compliant with UL/CSA and European Class X2 safety regulations, equipped with safety mechanism.
Applications
- Interference Suppressor
Key features
- High safety (with safety function installed)
- High moisture resistance (temperature-humidity bias test: 85°C, 85%, 240V [AC], 1000 hours (0.1 ≤ C ≤ 1.0 μF), 275V [AC]/500 hours)
- Compact
- Flame-retardant plastic case and non-combustible resin
- RoHS compliant
