TECH PUBLIC

FP6291LR

800kHz~1.2MHz Boost Adjustable 2.5A SOT-23-6 Voltage Regulators - DC DC Switching Regulators

SOT-23-6RoHSActive

Manufacturer: TECH PUBLIC
Manufacturer part #: FP6291LR
Store part #: C52817104
Package / case: SOT-23-6
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,665 in stock

#C52817104

Stock & price checked 12 days ago

Quantity	Unit price	Pack price
5+	₹11.72	₹58.60
50+	₹9.25	₹462.50
150+	₹8.00	₹1,200.00
500+	₹7.08	₹3,540.00
3,000+	₹6.32	₹18,960.00
6,000+	₹5.95	₹35,700.00

Quantity (min 5, multiples of 5)

5 × ₹11.72

₹58.60

excl. GST

₹69.15 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

FP6291LR

₹58.60 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+85℃
Frequency - Switching: 800kHz~1.2MHz
Function: Boost
Number of Outputs: 1
Features: Adjustable current limiting;Overcurrent Protection
Output Type: Adjustable
Topology: Boost
Operating Voltage: 2.6V~6V
Switch tube (built-in/external): Built-in
Output Current: 2.5A
Quiescent Current: 190uA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.528 g

Overview

This is a current-mode boost DC-DC converter. The PWM circuit with an integrated 0.2Ω power MOSFET enables high power efficiency. An internal compensation network reduces the external component count to a minimum of 6. The non-inverting input of the error amplifier is connected to a 0.6V precision reference voltage, and an internal soft-start function reduces inrush current.
