Advanced Analog Technology

FP7126LR-G1

Buck 1 DC-DC 8V~12V SOT23-6 LED Drivers ICs RoHS

SOT23-6ROHS CompliantActive

LED Driver with Average-Mode Constant Current Control

Manufacturer: Advanced Analog Technology
Manufacturer part #: FP7126LR-G1
Store part #: C6847473
Package / case: SOT23-6
Category: LED Drivers ICs
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,925 in stock

#C6847473

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
5+	₹36.58	₹182.90
50+	₹28.92	₹1,446.00
150+	₹25.63	₹3,844.50
500+	₹21.54	₹10,770.00
3,000+	₹19.71	₹59,130.00
6,000+	₹18.61	₹1,11,660.00

Quantity (min 5, multiples of 5)

5 × ₹36.58

₹182.90

excl. GST

₹215.82 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

FP7126LR-G1

₹182.90 for 5 + GST

Specifications

Features: Over-Temperature Protection (OTP);Short Circuit Protection
Switch Tube (Built-In/External): External
Operating temperature: -25℃~+85℃
Topology: Buck
Number of Channels: 1
Type: DC-DC
Voltage - Input(DC): 8V~12V
Constant Current Accuracy: 2%

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.046 g

Overview

The FP7126 is an average current mode control LED driver IC operating in a constant off-time mode. FP7126 does not produce a peak-to-average error, and therefore greatly improves accuracy, line and load regulation of the LED current without any need for loop compensation or high-side current sensing. The output LED current accuracy is ±2%. PWM dimming input is provided that accepts an external control TTL compatible signal. The output current can be programmed by an internal 250mV reference.
