VISHAYDatasheet (PDF)
GMF05LC-HSF-GS08
12.5VC Clamp 5A@8/20us Ipp ESD DIODE UFDFN-6-EP
UFDFN-6-EPROHS CompliantActive
ESD DIODE 5VWM 12.5VC UFDFN-6-EP
- Manufacturer
- VISHAY
- Manufacturer part #
- GMF05LC-HSF-GS08
- Store part #
- C1976416
- Package / case
- UFDFN-6-EP
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,210 in stock
#C1976416
Stock & price checked 37 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹21.92 | ₹109.60 |
| 50+ | ₹18.96 | ₹948.00 |
| 150+ | ₹17.69 | ₹2,653.50 |
| 500+ | ₹16.10 | ₹8,050.00 |
| 3,000+ | ₹15.40 | ₹46,200.00 |
| 6,000+ | ₹14.98 | ₹89,880.00 |
5 × ₹21.92
₹109.60
excl. GST
₹129.33 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
GMF05LC-HSF-GS08
₹109.60 for 5 + GST
Specifications
- Clamping Voltage
- 12.5V
- Operating Temperature
- -55℃~+125℃
- Peak Pulse Current (Ipp)
- 5A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 70W@8/20us
- Number of Channels
- 5
- Voltage - Breakdown
- 8V
- type
- ESD
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 100nA
- Reverse Stand-Off Voltage (Vrwm)
- 5V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.033 g
