GN SemicDatasheet (PDF)
GN431A 0.5%
Shunt Voltage Reference IC Adjustable 100mA SOT-23
SOT-23RoHSActive
Three-terminal adjustable shunt voltage regulator
- Manufacturer
- GN Semic
- Manufacturer part #
- GN431A 0.5%
- Store part #
- C3036718
- Package / case
- SOT-23
- Category
- Voltage Reference
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,840 in stock
#C3036718
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹5.01 | ₹50.10 |
| 100+ | ₹4.07 | ₹407.00 |
| 300+ | ₹3.61 | ₹1,083.00 |
| 3,000+ | ₹3.16 | ₹9,480.00 |
| 6,000+ | ₹2.88 | ₹17,280.00 |
| 9,000+ | ₹2.75 | ₹24,750.00 |
10 × ₹5.01
₹50.10
excl. GST
₹59.12 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
GN431A 0.5%
₹50.10 for 10 + GST
Specifications
- Output Voltage
- 2.495V
- Tolerance
- ±0.5%
- Voltage - Supply
- 2.483V~36V
- Minimum Cathode Current for Regulation
- 450uA
- Reference Type
- Parallel
- Output Current
- 100mA
- Operating Temperature
- -40℃~+85℃
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.033 g
Overview
GN431A is a three-terminal adjustable shunt regulator with excellent temperature stability, which can serve as a replacement for Zener diodes in many applications.
Applications
- Shunt regulator
- Series regulator
- Switching regulator
- Voltage reference regulator
Key features
- Low dynamic output impedance
- Sink current capability: 0.5 to 100mA
- Low output noise voltage
- Fast turn-on response
