HGSEMI

HGFP6291M6/TR

Boost 1MHz Adjustable 2.5A SOT-23-6 Voltage Regulators - DC DC Switching Regulators

SOT-23-6RoHSActive

Manufacturer: HGSEMI
Manufacturer part #: HGFP6291M6/TR
Store part #: C49384173
Package / case: SOT-23-6
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,835 in stock

#C49384173

Stock & price checked 38 h ago

Quantity	Unit price	Pack price
5+	₹17.44	₹87.20
50+	₹13.79	₹689.50
150+	₹11.96	₹1,794.00
500+	₹10.58	₹5,290.00
3,000+	₹9.49	₹28,470.00
6,000+	₹8.94	₹53,640.00

Quantity (min 5, multiples of 5)

5 × ₹17.44

₹87.20

excl. GST

₹102.90 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

HGFP6291M6/TR

₹87.20 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+85℃@(TA)
Number of Outputs: 1
Function: Boost
Frequency - Switching: 1MHz
Features: Adjustable current limiting;Overcurrent Protection
Output Type: Adjustable
Topology: Boost
Operating Voltage: 2.6V~6V
Switch tube (built-in/external): Built-in
Output Current: 2.5A
Quiescent Current: 190uA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.047 g

Overview

HGFP6291 is a current-mode boost DC-DC converter. Its integrated PWM circuit and 0.2Ω power MOSFET deliver high efficiency and low power consumption. The internal compensation network minimizes external component count. The non-inverting input of the error amplifier is connected to a 0.6V precision reference voltage; combined with the internal soft-start function, inrush current is effectively suppressed. The device is available in a SOT-23-6 package, helping to conserve PCB space.
