NexperiaDatasheet (PDF)
HPZR-C14-QX
1 Independent 13.3V~14.7V SC-70 Single Zener Diodes RoHS
SC-70ROHS CompliantActive
- Manufacturer
- Nexperia
- Manufacturer part #
- HPZR-C14-QX
- Store part #
- C7508478
- Package / case
- SC-70
- Category
- Single Zener Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
200 in stock
#C7508478
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹94.70 | ₹94.70 |
| 10+ | ₹75.81 | ₹758.10 |
| 30+ | ₹66.47 | ₹1,994.10 |
| 100+ | ₹57.13 | ₹5,713.00 |
| 500+ | ₹51.70 | ₹25,850.00 |
| 1,000+ | ₹48.66 | ₹48,660.00 |
1 × ₹94.70
₹94.70
excl. GST
₹111.75 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
HPZR-C14-QX
₹94.70 for 1 + GST
Specifications
- Diode Configuration
- 1 Independent
- Tolerance
- ±5%
- Pd - Power Dissipation
- 1.154W
- Reverse Leakage Current (Ir)
- 2.5uA@12V
- Zener Voltage(Range)
- 13.3V~14.7V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.052 g
Overview
High power voltage regulator diodes in a CFP3 (SOD123W) small and flat lead low- profile Surface- Mounted Device (SMD) plastic package.
Applications
- Low-correct general regulation functions
Key features
- Total power dissipation: ≤ 5.5 W @ Tsp = 75℃, measured zero lead length
- Tolerance series: Approximately ± 5%
- Working voltage range: nominal 3.0 V to 75 V
- ESD maximum rating 30 kV according IEC 61000-4-2 (contact discharge)
- Qualified according to AEC-Q101 and recommended for use in automotive applications
