HXY MOSFETDatasheet (PDF)
HSMF28AT13
45.4VC Clamp 4.4A Ipp TVS DIODE SOD-123FL
SOD-123FLRoHSActive
TVS DIODE 28VWM 45.4VC SOD-123FL
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- HSMF28AT13
- Store part #
- C42401917
- Package / case
- SOD-123FL
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
180 in stock
#C42401917
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.57 | ₹71.40 |
| 200+ | ₹2.86 | ₹572.00 |
| 600+ | ₹2.45 | ₹1,470.00 |
| 3,000+ | ₹2.13 | ₹6,390.00 |
| 9,000+ | ₹1.93 | ₹17,370.00 |
| 21,000+ | ₹1.81 | ₹38,010.00 |
20 × ₹3.57
₹71.40
excl. GST
₹84.25 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
HSMF28AT13
₹71.40 for 20 + GST
Specifications
- Clamping Voltage
- 45.4V
- Operating Temperature
- -65℃~+150℃
- Peak Pulse Current (Ipp)
- 4.4A
- Peak Pulse Power Dissipation (Ppp)
- 200W
- Number of Channels
- 1
- Voltage - Breakdown
- 34.4V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 28V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.035 g
