HUF75344P3
285W 55V 75A 6.5mΩ@10V 1 N-channel N-Channel TO-220AB-3 Single FETs, MOSFETs RoHS
TO-220AB-3ROHS3 CompliantActive
- Manufacturer
- onsemi
- Manufacturer part #
- HUF75344P3
- Store part #
- C898686
- Package / case
- TO-220AB-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
25 in stock
#C898686
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹708.02 | ₹708.02 |
| 10+ | ₹698.35 | ₹6,983.50 |
| 30+ | ₹691.68 | ₹20,750.40 |
| 100+ | ₹685.01 | ₹68,501.00 |
1 × ₹708.02
₹708.02
excl. GST
₹835.46 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 800 per tube
HUF75344P3
₹708.02 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 1.17nF
- Ciss-Input Capacitance
- 3.2nF
- Pd - Power Dissipation
- 285W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 55V
- Current - Continuous Drain(Id)
- 75A
- Reverse Transfer Capacitance (Crss)
- 310pF
- RDS(on)
- 6.5mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 175nC
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 800 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.872 g
Overview
These N-channel power MOSFETs are manufactured using the innovative UltraFET process. This advanced process technology achieves the lowest possible on-resistance per unit silicon area, delivering outstanding performance. The devices can withstand high energy in avalanche mode, with diodes featuring extremely short reverse recovery time and minimal stored charge. They are specifically designed for power-efficiency-critical applications such as switching regulators, switching converters, motor drivers, relay drivers, low-voltage bus switches, and power management in portable and battery-powered products.
Applications
- Switching regulators
- Switching converters
- Motor drivers
- Relay drivers
- Low-voltage bus switches
- Power management for portable and battery-powered products
Key features
- 75A, 55V
- Simulation Models
- Temperature-compensated PSPICE and SABER models
- Thermal impedance PSPICE and SABER models available online
- Peak current vs. pulse width curves
- Unclamped Inductive Switching (UIS) rating curves
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | IPP048N12N3 G#C537133Infineon · TO-220-3 | Infineon | TO-220-3 | 2 | ₹678.13 · 2 in stock | View |
 | STP140NF75#C457466ST · TO-220 | ST | TO-220 | 295 | ₹218.04 · 295 in stock | View |
 | IPP100N12S3-05#C537155Infineon · TO-220-3 | Infineon | TO-220-3 | 10 | ₹731.01 · 10 in stock | View |
 | CMP060N10#C5203909Cmos · TO-220 | Cmos | TO-220 | 7 | ₹127.35 · 7 in stock | View |
 | IRF3205ZPBF#C2612Infineon · TO-220AB | Infineon | TO-220AB | 501 | ₹78.49 · 501 in stock | View |
