HEXIN

HX1113-AEC

Buck Switching Regulator IC Adjustable 0.6V~5.5V 2 Output 700mA SOT-23-6L

SOT-23-6LRoHSActive

Dual-channel synchronous step-down DC/DC converter

Manufacturer: HEXIN
Manufacturer part #: HX1113-AEC
Store part #: C42412963
Package / case: SOT-23-6L
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,760 in stock

#C42412963

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹15.16	₹75.80
50+	₹13.24	₹662.00
150+	₹12.42	₹1,863.00
500+	₹11.39	₹5,695.00
3,000+	₹10.94	₹32,820.00
6,000+	₹10.66	₹63,960.00

Quantity (min 5, multiples of 5)

5 × ₹15.16

₹75.80

excl. GST

₹89.44 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

HX1113-AEC

₹75.80 for 5 + GST

Specifications

Operating Temperature: -40℃~+85℃
Number of Outputs: 2
Function: Step-down type
Frequency - Switching: 1.4MHz
Features: Overcurrent Protection
Output Type: Adjustable
Topology: Buck
Operating Voltage: 2.5V~5.5V
Switch tube (built-in/external): Built-in
Output Voltage: 600mV~5.5V
Output Current: 700mA
Quiescent Current: 70uA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.053 g

Overview

Hx1113 is a high-efficiency synchronous dual-channel 700mA synchronous buck DC/DC converter operating over an input voltage range of 2.5V to 5.5V. It integrates two synchronous buck DC/DC converters. 100% duty cycle capability extends battery life in portable devices, with a quiescent current of 70μA at no load. The switching frequency is internally set to 1.4MHz, allowing the use of small SMT inductors and capacitors. The Hx1113 converter is available in an industry-standard SOT-23-6L package (or as required).
