HEXIN

HX3033A-AFC

Boost 400kHz Adjustable 5V~18V 700mA SOT-23-6L Voltage Regulators - DC DC Switching Regulators

SOT-23-6LRoHSActive

High Efficiency Low-Voltage Step-Up DC/DC Converter

Manufacturer: HEXIN
Manufacturer part #: HX3033A-AFC
Store part #: C521270
Package / case: SOT-23-6L
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

6,045 in stock

#C521270

Stock & price checked 2 days ago

Quantity	Unit price	Pack price
5+	₹25.34	₹126.70
50+	₹19.90	₹995.00
150+	₹17.57	₹2,635.50
500+	₹14.66	₹7,330.00
3,000+	₹13.36	₹40,080.00
6,000+	₹12.58	₹75,480.00

Quantity (min 5, multiples of 5)

5 × ₹25.34

₹126.70

excl. GST

₹149.51 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

HX3033A-AFC

₹126.70 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+85℃@(TA)
Function: Boost
Frequency - Switching: 400kHz
Number of Outputs: 1
Output Type: Adjustable
Topology: Boost
Operating Voltage: 2.5V~5V
Switch tube (built-in/external): Built-in
Output Voltage: 5V~18V
Output Current: 700mA
Quiescent Current: 692uA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.047 g

Overview

The HX3033A is a compact, high efficiency, and low voltage step-up DC/DC converter with an Adaptive Current Mode PWM control loop, includes an error amplifier, ramp generator, comparator, switch pass element and driver in which providing a stable and high efficient operation over a wide range of load currents. It operates in stable waveforms without external compensation. HX3033A can operate from an input voltage as low as 2.2V. HX3033A can generate 18V up to 700mA from a 5V supply. The HX3033A is available in a low profile SOT-23-6L package.
