InfineonDatasheet (PDF)
IPB180N04S400ATMA1
N-Channel 40V 180A 300W Surface Mount TO-263-7-3
TO-263-7-3ROHS3 CompliantActive
MOSFET N-CH 40V 180A TO-263-7-3
- Manufacturer
- Infineon
- Manufacturer part #
- IPB180N04S400ATMA1
- Store part #
- C3279266
- Package / case
- TO-263-7-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C3279266
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹1,447.84 | ₹1,447.84 |
| 10+ | ₹1,256.20 | ₹12,562.00 |
| 30+ | ₹1,139.27 | ₹34,178.10 |
| 100+ | ₹1,041.31 | ₹1,04,131.00 |
1 × ₹1,447.84
₹1,447.84
excl. GST
₹1,708.45 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
IPB180N04S400ATMA1
₹1,447.84 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 4.9nF
- Ciss-Input Capacitance
- 22.88nF
- Pd - Power Dissipation
- 300W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 180A
- Reverse Transfer Capacitance (Crss)
- 300pF
- RDS(on)
- 0.98mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 286nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.04 g
Overview
Key features
- N-channel - Enhancement mode
- AEC qualified
- MSL1 up to 260°C peak reflow
- 175°C operating temperature
- Green product (RoHS compliant)
- Ultra low Rds(on)
- 100% Avalanche tested
