VBsemi ElecDatasheet (PDF)
IPB180N10S403ATMA1-VB
N-Channel 100V 180A 300W TO-263-7
TO-263-7RoHSActive
MOSFET N-CH 100V 180A TO-263-7
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- IPB180N10S403ATMA1-VB
- Store part #
- C46753315
- Package / case
- TO-263-7
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C46753315
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹526.38 | ₹526.38 |
| 10+ | ₹468.49 | ₹4,684.90 |
| 50+ | ₹301.30 | ₹15,065.00 |
| 100+ | ₹264.07 | ₹26,407.00 |
| 500+ | ₹247.31 | ₹1,23,655.00 |
| 800+ | ₹240.12 | ₹1,92,096.00 |
1 × ₹526.38
₹526.38
excl. GST
₹621.13 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
IPB180N10S403ATMA1-VB
₹526.38 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 100V
- Current - Continuous Drain(Id)
- 180A
- Output Capacitance(Coss)
- 246pF
- Ciss-Input Capacitance
- 8.2nF
- Pd - Power Dissipation
- 300W
- Reverse Transfer Capacitance (Crss)
- 21pF
- RDS(on)
- 3mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 105nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4.5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.31 g
Overview
Applications
- Power Supply
- Uninterruptible Power Supply
- AC/DC Switch Mode Power Supply
- Lighting
- Synchronous Rectification
- DC/DC Converter
- Motor Drive Switch
- DC/AC Inverter
- Solar Micro Inverter
- Class D Audio Amplifier
Key features
- SGT technology power MOSFET
- Maximum junction temperature 175°C
- 100% Rg and UIS tested
- RoHS compliant
- Halogen-free
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | IPB015N08N5ATMA1-VB#C22395950VBsemi Elec · TO-263-7 | VBsemi Elec | TO-263-7 | 5 | ₹362.98 · 5 in stock | View |
 | VBGL7103#C21264525VBsemi Elec · TO-263-7L | VBsemi Elec | TO-263-7L | 5 | ₹362.98 · 5 in stock | View |
 | IPB180N10S4-02-VB#C21264527VBsemi Elec · TO-263-7L | VBsemi Elec | TO-263-7L | 5 | ₹362.98 · 5 in stock | View |
 | IPB025N10N3G-VB#C21264526VBsemi Elec · TO-263-7L | VBsemi Elec | TO-263-7L | 50 | ₹395.11 · 50 in stock | View |
 | IPF015N10N5ATMA1-VB#C47993813VBsemi Elec · TO-263-7L | VBsemi Elec | TO-263-7L | 5 | ₹468.92 · 5 in stock | View |
