InfineonDatasheet (PDF)
IPZ40N04S58R4ATMA1
34W 40V 40A 8.4mΩ@10V 1 N-channel N-Channel TSDSON-8 Single FETs, MOSFETs RoHS
TSDSON-8ROHS3 CompliantActive
- Manufacturer
- Infineon
- Manufacturer part #
- IPZ40N04S58R4ATMA1
- Store part #
- C3279297
- Package / case
- TSDSON-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
128 in stock
#C3279297
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹92.15 | ₹92.15 |
| 10+ | ₹74.76 | ₹747.60 |
| 30+ | ₹66.07 | ₹1,982.10 |
| 100+ | ₹57.38 | ₹5,738.00 |
| 500+ | ₹52.15 | ₹26,075.00 |
| 1,000+ | ₹49.55 | ₹49,550.00 |
1 × ₹92.15
₹92.15
excl. GST
₹108.74 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
IPZ40N04S58R4ATMA1
₹92.15 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 215pF
- Ciss-Input Capacitance
- 771pF
- Pd - Power Dissipation
- 34W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 40A
- Reverse Transfer Capacitance (Crss)
- 20pF
- RDS(on)
- 8.4mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 13.7nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3.4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.065 g
Overview
Applications
- General automotive applications.
Key features
- OptiMOS power MOSFET for automotive applications
- N-channel - Enhancement mode - Standard level
- AEC Q101 qualified
- MSL1 up to 260°C peak reflow temperature
- 175°C operating temperature
- Green product (RoHS compliant)
- 100% avalanche tested
