InfineonDatasheet (PDF)
IQE006NE2LM5CGATMA1
N-Channel 25V 298A 89W Through Hole IPAK(TO-251AA)
IPAK(TO-251AA)ROHS3 CompliantActive
MOSFET N-CH 25V 298A IPAK(TO-251AA)
- Manufacturer
- Infineon
- Manufacturer part #
- IQE006NE2LM5CGATMA1
- Store part #
- C3278295
- Package / case
- IPAK(TO-251AA)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
54 in stock
#C3278295
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹328.47 | ₹328.47 |
| 10+ | ₹276.23 | ₹2,762.30 |
| 30+ | ₹243.48 | ₹7,304.40 |
| 100+ | ₹209.88 | ₹20,988.00 |
| 500+ | ₹194.92 | ₹97,460.00 |
| 1,000+ | ₹188.20 | ₹1,88,200.00 |
1 × ₹328.47
₹328.47
excl. GST
₹387.59 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
IQE006NE2LM5CGATMA1
₹328.47 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 1.7nF
- Ciss-Input Capacitance
- 4.1nF
- Pd - Power Dissipation
- 89W
- Drain to Source Voltage
- 25V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 298A
- Reverse Transfer Capacitance (Crss)
- 130pF
- RDS(on)
- 0.5mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 28.5nC@4.5V
- Vgs
- ±16V
- Gate Threshold Voltage (Vgs(th))
- 1.6V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.205 g
Overview
Applications
- DC-DC converters and off-line UPS
- Distributed power architectures and voltage regulator modules (VRMs)
- Primary switching for 24V and 48V systems
- High-voltage synchronous rectifiers
Key features
- Ultra-low on-resistance RDS(on)
- 100% avalanche tested
- Excellent thermal resistance performance
- N-channel, logic level
- Lead-free lead finish; RoHS compliant
- Halogen-free per IEC61249-2-21
