JoulWatt TechDatasheet (PDF)
JW5357MSOTB#TR
Buck Switching Regulator IC Adjustable 3A SOT-23-6
SOT-23-6RoHSActive
IC REG BUCK ADJ 3A SOT-23-6
- Manufacturer
- JoulWatt Tech
- Manufacturer part #
- JW5357MSOTB#TR
- Store part #
- C5197556
- Package / case
- SOT-23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
41,360 in stock
#C5197556
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.74 | ₹63.70 |
| 50+ | ₹10.09 | ₹504.50 |
| 150+ | ₹8.76 | ₹1,314.00 |
| 500+ | ₹7.77 | ₹3,885.00 |
| 2,500+ | ₹7.04 | ₹17,600.00 |
| 5,000+ | ₹6.64 | ₹33,200.00 |
5 × ₹12.74
₹63.70
excl. GST
₹75.17 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
JW5357MSOTB#TR
₹63.70 for 5 + GST
Specifications
- Number of Outputs
- 1
- Function
- Step-down type
- Frequency - Switching
- 600kHz
- Features
- Hiccup current limiting;Light load efficient mode;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4.5V~18V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 3A
- Quiescent Current
- 220uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.047 g
Overview
The JW(odot)5357M is a monolithic buck switching regulator based on I2 architecture for fast transient response. Operating with an input range of 4.5V to 18Vz, JW5357M delivers 3A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, JW5357M operates in low frequency to maintain high efficiency. JW5357M guarantees robustness with output short protection, thermal protection, current run-away protection and input under voltage lockout. JW5357M is available in SOT23-6 package, which provide a compact solution with minimal external components.
Applications
- Distributed Power Systems
- Networking Systems
- FPGA, DSP, ASIC Power Supplies
- Green Electronics/ Appliances
- Notebook Computers
Key features
- 4.5V to 18V operating input range, 3A output current
- Up to 95% efficiency
- PFM at light load
- 600kHz switching frequency
- Internal soft-start
- Input under-voltage lockout
- Current run-away protection
- Output short protection
- Thermal protection
- Available in SOT23-6 package
