Leadtrend

LD8116DGL

1.5kHz 1 20mA 15V~56V SOT-26 LED Drivers ICs RoHS

SOT-26ROHS CompliantActive

Flexible Dimming Solution by PWM / 0-10V / Potentiometer

Manufacturer: Leadtrend
Manufacturer part #: LD8116DGL
Store part #: C648784
Package / case: SOT-26
Category: LED Drivers ICs
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

855 in stock

#C648784

Stock & price checked 45 h ago

Quantity	Unit price	Pack price
5+	₹46.29	₹231.45
50+	₹36.63	₹1,831.50
150+	₹32.51	₹4,876.50
500+	₹27.35	₹13,675.00
3,000+	₹24.09	₹72,270.00
6,000+	₹22.72	₹1,36,320.00

Quantity (min 5, multiples of 5)

5 × ₹46.29

₹231.45

excl. GST

₹273.11 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

LD8116DGL

₹231.45 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Frequency - Switching: 1.5kHz
Features: Over-Temperature Protection (OTP)
Switch Tube (Built-In/External): Built-in
Operating temperature: -40℃~+125℃
Number of Channels: 1
Output Current: 20mA
Voltage - Input(DC): 15V~56V
Constant Current Accuracy: 2.5%

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.046 g

Overview

The LD8116D contains a processor which can convert the three different inputs of dimmer type include 0~10V DC potential, 0~100% duty cycle PWM (Plus Width Modulation) signal and potentiometer become a PWM signal output. It is easy to provide the isolation dimming control that via opto-coupler for smart LED lighting application. The device features include wide input voltage from 13V to 58V, adjustable bias current source for potentiometer and high precision LED dimming current.
