ROHMDatasheet (PDF)
LM2903DGKR
2 800uA 2mV MSOP-8 Comparators RoHS
MSOP-8ROHS3 CompliantActive
General-purpose Operational Amplifiers/Comparators
- Manufacturer
- ROHM
- Manufacturer part #
- LM2903DGKR
- Store part #
- C7500473
- Package / case
- MSOP-8
- Category
- Comparators
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,460 in stock
#C7500473
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹25.88 | ₹129.40 |
| 50+ | ₹20.53 | ₹1,026.50 |
| 150+ | ₹18.26 | ₹2,739.00 |
| 500+ | ₹15.40 | ₹7,700.00 |
| 2,500+ | ₹14.13 | ₹35,325.00 |
| 5,000+ | ₹13.36 | ₹66,800.00 |
5 × ₹25.88
₹129.40
excl. GST
₹152.69 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
LM2903DGKR
₹129.40 for 5 + GST
Specifications
- Number of Channels
- 2
- Input Offset Current(Ios)
- 5nA
- Output Mode
- TTL;MOS;CMOS
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 25nA
- Output Type
- Open Collector
- Propagation Delay(tpd)
- 1.3us
- Quiescent Current(Iq)
- 800uA
- Vos - Input Offset Voltage
- 2mV
- Maximum Power Supply Range (Vdd-Vss)
- 36V
- Single Supply
- 2V~36V
- Response Time (tr)
- 1.3us
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.15 g
Overview
The Universal Standard family LM393 / LM339/ LM2903 / LM2901 monolithic ICs integrate two/four independent comparators on a single chip and feature high gain, low power consumption, and an operating voltage range from 2[V] to 36[V] (single power supply).
Key features
- Operating temperature range Commercial Grade LM339/393 family : 0[°C] to + 70[°C] Extended Industrial Grade LM2903/2901 family : -40[°C] to +125[°C]
- Open collector output
- Single / dual power supply compatible
- Low supply current 0.8[mA] typ. (LM393/339/2903/2901 family)
- Low input-bias current: 25[nA] typ.
- Low input-offset voltage: 2[mV] typ.
- Differential input voltage range equal to maximum rating
- Low output saturation voltage
- TTL,MOS,CMOS compatible output
