LMC7660IMX/NOPB

Inverted 10kHz -10V~-1.5V SOIC-8 Voltage Regulators - DC DC Switching Regulators RoHS

SOIC-8ROHS3 CompliantActive

Switched Capacitor Voltage Converter

Manufacturer: TI
Manufacturer part #: LMC7660IMX/NOPB
Store part #: C7556
Package / case: SOIC-8
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

5,412 in stock

#C7556

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹103.11	₹103.11
10+	₹82.22	₹822.20
30+	₹71.79	₹2,153.70
100+	₹61.57	₹6,157.00
500+	₹55.26	₹27,630.00
1,000+	₹52.22	₹52,220.00

Quantity (min 1)

1 × ₹103.11

₹103.11

excl. GST

₹121.67 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,500 per reel

LMC7660IMX/NOPB

₹103.11 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+85℃
Function: Inverted
Frequency - Switching: 10kHz
Features: Cascade support;Output short-circuit protection
Operating Voltage: 1.5V~10V
Output Voltage: -10V~-1.5V
Quiescent Current: 200uA
Energy Efficiency: 95%

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.173 g

Overview

The LMC7660 is a CMOS voltage converter capable of converting a positive voltage in the range of +1.5V to +10V to the corresponding negative voltage of -1.5V to -10V. The LMC7660 is a pin-for-pin replacement for the industry-standard 7660. The converter features: operation over full temperature and voltage range without need for an external diode, low quiescent current, and high power efficiency. The LMC7660 uses its built-in oscillator to switch 4 power MOS switches and charge two inexpensive electrolytic capacitors.

Key features

Operation Over Full Temperature and Voltage Range without an External Diode
Low Supply Current, 200 μA Max
Pin-for-pin Replacement for the 7660
Wide Operating Range 1.5V to 10V
97% Voltage Conversion Efficiency
95% Power Conversion Efficiency
Easy to Use, Only 2 External Components
Extended Temperature Range

Alternatives

Similar parts — check the datasheet before substituting.

Part		Manufacturer	Package	Stock	Price from (excl. GST)	Action
	ICL7660M/TR#C356724HGSEMI · SOP-8	HGSEMI	SOP-8	34,105	₹23.62 · 34,105 in stock	View
	LMC7660M/TR#C434489HGSEMI · SOP-8	HGSEMI	SOP-8	4,405	₹49.49 · 4,405 in stock	View
