LMR36506MSCQRPERQ1
2.2MHz Step-down type Adjustable 600mA VQFN-9(2.1x2.1) Voltage Regulators - DC DC Switching Regulators RoHS
VQFN-9(2.1x2.1)ROHS3 CompliantActive
3-V to 65-V, 0.6-A Synchronous Buck Converter Optimized for Size and Light Load Efficiency
- Manufacturer
- TI
- Manufacturer part #
- LMR36506MSCQRPERQ1
- Store part #
- C1882561
- Package / case
- VQFN-9(2.1x2.1)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,888 in stock
#C1882561
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹1,309.02 | ₹1,309.02 |
| 10+ | ₹1,215.94 | ₹12,159.40 |
| 30+ | ₹1,160.50 | ₹34,815.00 |
| 100+ | ₹1,104.61 | ₹1,10,461.00 |
| 500+ | ₹1,078.73 | ₹5,39,365.00 |
| 1,000+ | ₹1,067.21 | ₹10,67,210.00 |
1 × ₹1,309.02
₹1,309.02
excl. GST
₹1,544.64 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
LMR36506MSCQRPERQ1
₹1,309.02 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+150℃@(TJ)
- Frequency - Switching
- 2.2MHz
- Function
- Step-down type
- Number of Outputs
- 1
- Features
- EMI optimization (spread spectrum);Frequency synchronization;Light load efficient mode;Operating status indication
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 3V~65V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 600mA
- Output Voltage
- 3.3V;5V
- Quiescent Current
- 18uA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 2 (1 year)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.02 g
Overview
The LMR36506-Q1 is the smallest 65 V, 0.6 A synchronous step-down DC/DC converter in 2-mm x 2-mm HotRod package. This easy-to-use converter can handle input voltage transients up to 70 V, provide excellent EMI performance and support fixed 3.3 V, 5 V and other adjustable output voltages. The LMR36506-Q1 uses peak current mode control architecture with internal compensation and maintains stable operation with minimal output capacitance. The wide input operating range of the LMR36506-Q1 helps it remain functional during a deep input voltage sag condition, making it an excellent choice for automotive applications withstanding severe cold crank start impulses. The PGOOD flag in the LMR36506-Q1 provides precise indication of the output voltage status, eliminating the requirement for an external supervisor. A seamless transition from FPWM to PFM, with an ultra-low standby quiescent current allows the LMR36506-Q1 to support much higher system efficiency at low output loads. The MODE/SYNC pin variant helps to synchronize the LMR36506-Q1 to an external clock. With the right resistor selection, the LMR36506-Q1 RT pin variant can also be externally programmed to any desired switching frequency of operation. The rich feature set of the LMR36506-Q1 is designed to simplify implementation for a wide range of automotive end equipments.
Applications
- Advanced driver assistance systems (ADAS)
- Body electronics and lighting
- Infotainment and cluster
Key features
- AEC-Q100-qualified for automotive applications: Device temperature grade 1: -40°C to +125°C, TA
- Functional Safety-Capable Documentation available to aid functional safety system design
- >80% efficiency at 1 mA 4 μA IO (switching) at 24 VIN to 3.3 VOUT (fixed output option)
- Miniature solution size and low component cost
- 2-mm x 2-mm HotRod package with wettable flanks
- Internal compensation
- Designed for automotive applications: Junction temperature range -40°C to +150°C
- Pseudo-random spread spectrum compatible with CISPR 25 EMI standard
- Wide input voltage range: 3.0 V (falling threshold) to 65 V
- Adjustable, 3.3-V and 5-V fixed output voltage options available
- Synchronizable with MODE/SYNC pin variant
- Adjustable FSW: 200 kHz to 2.2 MHz with RT pin variant
- Pin compatible with LMR36503-Q1 (65 V, 300 mA)
