LOWPOWER

LP6260SQVF

1.2MHz Boost Fixed 5V~5.2V 1A TDFN-6-EP(2x2) Voltage Regulators - DC DC Switching Regulators

TDFN-6-EP(2x2)RoHSActive

Ultra low IQ Synchronous Boost Convertor

Manufacturer: LOWPOWER
Manufacturer part #: LP6260SQVF
Store part #: C2905706
Package / case: TDFN-6-EP(2x2)
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,465 in stock

#C2905706

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
5+	₹25.71	₹128.55
50+	₹22.29	₹1,114.50
150+	₹20.82	₹3,123.00
500+	₹18.99	₹9,495.00
2,500+	₹18.18	₹45,450.00
4,000+	₹17.69	₹70,760.00

Quantity (min 5, multiples of 5)

5 × ₹25.71

₹128.55

excl. GST

₹151.69 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

LP6260SQVF

₹128.55 for 5 + GST

Specifications

Operating Temperature: -40℃~+85℃@(TA)
Frequency - Switching: 1.2MHz
Function: Boost
Number of Outputs: 1
Features: Load disconnect;Overcurrent Protection;Cycle-by-cycle current limiting
Output Type: Fixed
Topology: Boost
Operating Voltage: 1V~5V
Switch tube (built-in/external): Built-in
Output Voltage: 5V~5.2V
Output Current: 1A
Quiescent Current: 1uA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.035 g

Overview

The LP6260S device is a synchronous boost convertor with ultra-low quiescent current. It features a true-shutoff function that disconnects the input and output during shutdown and output short-circuit conditions. The LP6260S only consumes 1uA quiescent current under light load condition and can achieve up to 75% efficiency at 20uA load. It can achieve up to 93% efficiency at 200mA load from 3.3V to 5V conversion.
