LRCDatasheet (PDF)
LR432BTLT1G
1.24V~18V ±0.5% 100mA Adjustable SOT-23 Voltage Reference
SOT-23RoHSActive
Programmable Precision Reference
- Manufacturer
- LRC
- Manufacturer part #
- LR432BTLT1G
- Store part #
- C411185
- Package / case
- SOT-23
- Category
- Voltage Reference
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
38,330 in stock
#C411185
Stock & price checked 27 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹14.17 | ₹141.70 |
| 100+ | ₹11.26 | ₹1,126.00 |
| 300+ | ₹9.82 | ₹2,946.00 |
| 3,000+ | ₹7.74 | ₹23,220.00 |
| 6,000+ | ₹6.87 | ₹41,220.00 |
| 9,000+ | ₹6.43 | ₹57,870.00 |
10 × ₹14.17
₹141.70
excl. GST
₹167.21 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
LR432BTLT1G
₹141.70 for 10 + GST
Specifications
- Output Voltage
- 1.24V~18V
- Tolerance
- ±0.5%
- Minimum Cathode Current for Regulation
- 55uA
- Reference Type
- Parallel
- Output Current
- 100mA
- Operating Temperature
- -40℃~+125℃
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.034 g
Overview
The LR432XXTLT1G is a three-terminal adjustable regulator with a guaranteed thermal stability over applicable temperature ranges. The output voltage may be set to any value between V_REF (approximately 1.24V) and 18V with two external resistors. It provides very wide applications, including shunt regulator, series regulator, switching regulator, voltage reference and others.
Key features
- Precise Reference Voltage to 1.24V Guaranteed 0.5% Reference Voltage Tolerance Sink Current Capability, 55μA to 100mA
- Quick Turn-on
- Adjustable Output Voltage, Vo = V_REF to 18V
- 0.05Ω Typical Output Impedance
- The material of product is ROHS compliant and does not contain any Br, Cl, and Sb2O3
- ESD H M 7000V
