LTC3422EDD#TRPBF ADI

LTC3422EDD#TRPBF

850kHz~1.15MHz Boost Adjustable 2.25V~5.25V 700mA DFN-10-EP(3x3) Voltage Regulators - DC DC Switching Regulators RoHS

DFN-10-EP(3x3)ROHS3 CompliantActive

1.5A, 3MHz Synchronous Step-Up DC/DC Converter with Output Disconnect

Manufacturer: ADI
Manufacturer part #: LTC3422EDD#TRPBF
Store part #: C684760
Package / case: DFN-10-EP(3x3)
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

45 in stock

#C684760

Stock & price checked 2 days ago

Quantity	Unit price	Pack price
1+	₹962.35	₹962.35
10+	₹918.72	₹9,187.20
30+	₹892.14	₹26,764.20
100+	₹869.66	₹86,966.00

Quantity (min 1)

1 × ₹962.35

₹962.35

excl. GST

₹1,135.57 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,500 per reel

LTC3422EDD#TRPBF

₹962.35 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+85℃@(TA)
Frequency - Switching: 850kHz~1.15MHz
Function: Boost
Number of Outputs: 1
Features: Adjustable soft-start;Frequency synchronization;Light load efficient mode;Load disconnect;Overcurrent Protection
Output Type: Adjustable
Topology: Boost
Operating Voltage: 500mV~4.5V
Switch tube (built-in/external): Built-in
Output Voltage: 2.25V~5.25V
Output Current: 700mA
Quiescent Current: 25uA

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.11 g
