MICRONEDatasheet (PDF)
ME2805A263XG
200ms Active Low 700mV~7V 1 SOT-23 Supervisors
SOT-23RoHSActive
Ultra-small package High-precision Voltage Detector with delay circuit
- Manufacturer
- MICRONE
- Manufacturer part #
- ME2805A263XG
- Store part #
- C236764
- Package / case
- SOT-23
- Category
- Supervisors
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
36,060 in stock
#C236764
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.56 | ₹65.60 |
| 100+ | ₹5.25 | ₹525.00 |
| 300+ | ₹4.60 | ₹1,380.00 |
| 3,000+ | ₹4.11 | ₹12,330.00 |
| 6,000+ | ₹3.73 | ₹22,380.00 |
| 9,000+ | ₹3.53 | ₹31,770.00 |
10 × ₹6.56
₹65.60
excl. GST
₹77.41 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
ME2805A263XG
₹65.60 for 10 + GST
Specifications
- output type
- Push-pull
- Operating Temperature
- -40℃~+85℃
- Reset Timeout
- 200ms
- Reset Active Level
- Active Low
- standby current
- 900nA
- Voltage - Supply
- 700mV~7V
- ChipType
- Voltage Detector
- Threshold Voltage
- 2.63V
- Number of Voltages Monitored
- 1
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.033 g
Overview
ME2805 Series is a series of high-precision voltage detectors with a built-in delay time generator of fixed time developed using CMOS process. Internal oscillator and counter timer can delay the release signal without external parts. Detect voltage is extremely accurate with minimal temperature drift. CMOS output configurations are available.
Applications
- Power monitor for portable equipment such as notebook computers, digital still cameras, PDA, and cellular phones
- Constant voltage power monitor for cameras, video equipment and communication devices
- Power monitor for microcomputers and reset for CPUs
- System battery life and charge voltage monitors
Key features
- Highly accuracy: ±1%
- Low power consumption: TYP 0.9uA (VDD = 3V)
- Detect voltage range: 1.0V~6.5V in 0.1V increments
- Operating voltage range: 0.7V~7V
- Detect voltage temperature characteristics: TYP±100ppm/℃
- Output configuration: CMOS
