TDKDatasheet (PDF)
MLK1005S33NJT000
200mA 33nH ±5% 590mΩ 0402 Fixed Inductors RoHS
0402ROHS3 CompliantDiscontinued
FIXED IND 33nH 200mA 590mΩ 0402
- Manufacturer
- TDK
- Manufacturer part #
- MLK1005S33NJT000
- Store part #
- C275323
- Package / case
- 0402
- Category
- Fixed Inductors
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
850 in stock
#C275323
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 50+ | ₹1.06 | ₹53.00 |
| 500+ | ₹0.8335 | ₹416.75 |
| 1,500+ | ₹0.7012 | ₹1,051.80 |
| 10,000+ | ₹0.6218 | ₹6,218.00 |
| 20,000+ | ₹0.5557 | ₹11,114.00 |
| 50,000+ | ₹0.5292 | ₹26,460.00 |
50 × ₹1.06
₹53.00
excl. GST
₹62.54 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
MLK1005S33NJT000
₹53.00 for 50 + GST
Specifications
- Current Rating
- 200mA
- Inductance
- 33nH
- Tolerance
- ±5%
- Frequency - Self Resonant
- 2.5GHz
- DC Resistance(DCR)
- 590mΩ
- Q @ Frequency
- 7@100MHz
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Discontinued
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 50 (multiples of 50)
- Unit weight
- 0.012 g
Overview
Applications
- Smartphones, tablets, high-frequency modules (power amplifiers, voltage-controlled oscillators, front-end modules, etc.), Bluetooth, WLAN, UWB, tuners, and other high-frequency circuits in the mobile communications industry
- Application Guide: Smartphones/Tablets
Key features
- By adopting a gigahertz spiral laminated structure, a higher self-resonant frequency than MLG structure can be achieved while limiting Q factor degradation in the GHz band.
- Formed as a monolithic structure using ceramic and high-frequency conductive materials through multilayer and sintering processes; non-directional.
- Operating temperature range: -55°C ~ +125°C
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MLG1005S33NJTD25#C2042247TDK · 0402 | TDK | 0402 | 50 | ₹1.73 · 50 in stock | View |
 | MLG1005S33NJT000#C76772TDK · 0402 | TDK | 0402 | 10,050 | ₹1.40 · 10,050 in stock | View |
 | LQG15HS33NJ02D#C86062muRata · 0402 | muRata | 0402 | 1,30,900 | ₹2.75 · 1,30,900 in stock | View |
 | MLG1005S33NHTD25#C404644TDK · 0402 | TDK | 0402 | 5,560 | ₹3.31 · 5,560 in stock | View |
 | LQG15HS33NH02D#C2042295muRata · 0402 | muRata | 0402 | On request | ₹1.98 · 0 in stock | View |
