onsemi

MMBT3904TT1G

Bipolar (BJT) Transistor NPN 40V 200mA 300MHz 200mW Surface Mount SOT-416

PopularSOT-416ROHS3 CompliantActive

TRANS NPN 40V 200mA SOT-416

Manufacturer: onsemi
Manufacturer part #: MMBT3904TT1G
Store part #: C242260
Package / case: SOT-416
Category: Single Bipolar Transistors
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

32,020 in stock

#C242260

Stock & price checked 19 h ago

Quantity	Unit price	Pack price
20+	₹4.74	₹94.80
200+	₹3.73	₹746.00
600+	₹3.18	₹1,908.00
3,000+	₹2.84	₹8,520.00
9,000+	₹2.55	₹22,950.00
21,000+	₹2.39	₹50,190.00

Quantity (min 20, multiples of 20)

20 × ₹4.74

₹94.80

excl. GST

₹111.86 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

MMBT3904TT1G

₹94.80 for 20 + GST

Specifications

Current - Collector Cutoff: 50nA
Operating Temperature: -65℃~+150℃
Transition frequency(fT): 300MHz
Collector - Emitter Voltage VCEO: 40V
Emitter-Base Voltage VEBO: 6V
DC Current Gain: 100
Pd - Power Dissipation: 200mW
Current - Collector(Ic): 200mA
Number: 1 NPN
type: NPN
Vce Saturation(VCE(sat)): 300mV

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 20 (multiples of 20)
Unit weight: 0.036 g

Overview

This transistor is designed for general purpose amplifier applications. It is housed in the SOT−416/SC−75 package which is designed for low power surface mount applications.

Key features

S Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
