onsemiDatasheet (PDF)
MMQA12VT1G
17.3VC Clamp 1.39A Ipp ESD DIODE SC-74
SC-74ROHS3 CompliantActive
ESD DIODE 9.1VWM 17.3VC SC-74
- Manufacturer
- onsemi
- Manufacturer part #
- MMQA12VT1G
- Store part #
- C233404
- Package / case
- SC-74
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
945 in stock
#C233404
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹38.06 | ₹190.30 |
| 50+ | ₹32.96 | ₹1,648.00 |
| 150+ | ₹30.77 | ₹4,615.50 |
| 500+ | ₹28.03 | ₹14,015.00 |
| 3,000+ | ₹26.82 | ₹80,460.00 |
| 6,000+ | ₹26.09 | ₹1,56,540.00 |
5 × ₹38.06
₹190.30
excl. GST
₹224.55 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MMQA12VT1G
₹190.30 for 5 + GST
Specifications
- Clamping Voltage
- 17.3V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 1.39A
- Peak Pulse Power Dissipation (Ppp)
- 150W
- Number of Channels
- Four channels
- Voltage - Breakdown
- 12V
- type
- ESD
- Reverse Leakage Current (Ir)
- 75nA
- Polarity
- Unidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 9.1V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.035 g
