MST

MST1661TQ

9V~24V TO-252 LED Drivers ICs

TO-252RoHSActive

DIRECTION INDICATOR DRIVER FOR MOTORBIKE

Manufacturer: MST
Manufacturer part #: MST1661TQ
Store part #: C22395106
Package / case: TO-252
Category: LED Drivers ICs
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,490 in stock

#C22395106

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹65.53	₹65.53
10+	₹57.70	₹577.00
30+	₹53.78	₹1,613.40
100+	₹49.88	₹4,988.00
500+	₹47.60	₹23,800.00
1,000+	₹46.37	₹46,370.00

Quantity (min 1)

1 × ₹65.53

₹65.53

excl. GST

₹77.33 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

MST1661TQ

₹65.53 for 1 + GST

Specifications

Features: Over-Temperature Protection (OTP);Short Circuit Protection
Switch Tube (Built-In/External): Built-in
Voltage - Input(DC): 9V~24V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.528 g

Overview

The MST1661 is a monolithic device intended for building a complete flashing unit for two wheel vehicles. The device is connected between the battery positive terminal (VCC pin) and a mechanical switch to the right and/or left bulbs. As soon as the series switch connects the OUT pin to the bulbs, the device begins to turn on/off with a 50% duty cycle. An external capacitor connected between the CEXT pin and the OUT pin stores energy for powering the device during the ON phase. When a low load is detected (output current lower than Idf), flashing frequency is automatically doubled.
