MAXIC Tech

MT7601BE

LED Driver IC 1 Output ESOP8-150mil

ESOP8-150milROHS CompliantActive

High-voltage single-stage linear constant-current LED driver

Manufacturer: MAXIC Tech
Manufacturer part #: MT7601BE
Store part #: C7469800
Package / case: ESOP8-150mil
Category: LED Drivers ICs
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,680 in stock

#C7469800

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
10+	₹9.37	₹93.70
100+	₹7.46	₹746.00
300+	₹6.50	₹1,950.00
1,000+	₹5.78	₹5,780.00
5,000+	₹5.20	₹26,000.00
10,000+	₹4.92	₹49,200.00

Quantity (min 10, multiples of 10)

10 × ₹9.37

₹93.70

excl. GST

₹110.57 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

MT7601BE

₹93.70 for 10 + GST

Specifications

Features: Over-Temperature Protection (OTP)
Switch Tube (Built-In/External): Built-in
Number of Channels: 1
Type: AC-DC
Constant Current Accuracy: 5%

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.162 g

Overview

MT7601BE is a high-voltage single-stage linear constant-current LED driver IC with high output current accuracy, no EMI issues, and output current flexibly set by an external resistor.

Applications

LED candle bulbs, LED filament bulbs
LED tube lights, LED panel lights
LED globe bulbs, LED spotlights
Other LED lighting products

Key features

Integrated high-voltage power transistor and high-voltage supply circuit; minimal external components required
No magnetic components (inductors or transformers) needed; passes EMI effortlessly without additional components; streamlined system design with low total BOM
Thermal regulation feature automatically reduces output current when die temperature is excessive, enhancing system reliability
Simple peripheral circuit, low cost
Built-in 700V power transistor
Externally configurable LED current
LED output current accuracy: ±5%
EMI-free application system
Over-temperature auto-regulation
ESOP8 package
