NSC1002
200kHz DFN-12-EP(1.5x3) Voltage Regulators - DC DC Switching Regulators RoHS
DFN-12-EP(1.5x3)ROHS CompliantActive
Charge pump controller with three adjustable modes
- Manufacturer
- WXNSIC
- Manufacturer part #
- NSC1002
- Store part #
- C46473173
- Package / case
- DFN-12-EP(1.5x3)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,910 in stock
#C46473173
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹32.98 | ₹164.90 |
| 50+ | ₹25.85 | ₹1,292.50 |
| 150+ | ₹22.81 | ₹3,421.50 |
| 500+ | ₹18.99 | ₹9,495.00 |
| 3,000+ | ₹17.29 | ₹51,870.00 |
| 6,000+ | ₹16.27 | ₹97,620.00 |
5 × ₹32.98
₹164.90
excl. GST
₹194.58 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NSC1002
₹164.90 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Frequency - Switching
- 200kHz
- Function
- boost converter;Inverted
- Features
- Low ripple / low noise architecture
- Operating Voltage
- 2.3V~3.8V
- Output Voltage
- 4.5V~6V;-6V~-4.5V
- Energy Efficiency
- 80%
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.046 g
Overview
NSC1002 is a low-noise charge pump DC/DC controller capable of generating positive and negative voltages simultaneously. It operates with an input voltage range of 2.3V ~ 3.8V and output voltage ranges of 4.5V ~ 6V and -4.5V ~ -6V. With a simple peripheral circuit design, it is well-suited for compact battery-powered applications. The output voltage of NSC1002 is adjustable based on the operating mode, supporting three modes — X1.5, X2, and X3 — where the output voltage is a multiple of the supply voltage. This product is available in a space-saving DFN-12 package.
Applications
- Mobile Devices
- MP3 Players
- Smartphones
- LCD Power Supply
- Optical Components
- RF Amplifiers
- Portable Sensors
Key features
- Wide input supply voltage range: 2.3V ~ 3.8V
- Adjustable operating frequency
- Adjustable operating mode
- Positive output voltage: 5.7V in X1.5 mode, 5.6V in X2 mode, 6.6V in X3 mode
- Negative output voltage: -5.7V in X1.5 mode, -5.6V in X2 mode, -6.6V in X3 mode
- Inductor-free design with minimal external components
- VCI port operating current: 110mA for X1.5, X2, and X3 modes
- Operating temperature range: -40°C ~ 85°C
- DFN-12 package, 3×1.5×0.5mm
