NTMFSC4D2N10MC
N-Channel 100V 116A 122W Surface Mount DFN-8(4.9x5.8)
DFN-8(5.1x6.2)ROHS3 CompliantActive
MOSFET N-CH 100V 116A DFN-8(4.9x5.8)
- Manufacturer
- onsemi
- Manufacturer part #
- NTMFSC4D2N10MC
- Store part #
- C2902298
- Package / case
- DFN-8(5.1x6.2)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
11 in stock
#C2902298
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹489.79 | ₹489.79 |
| 10+ | ₹419.17 | ₹4,191.70 |
| 30+ | ₹377.23 | ₹11,316.90 |
| 100+ | ₹334.64 | ₹33,464.00 |
| 500+ | ₹315.09 | ₹1,57,545.00 |
| 1,000+ | ₹306.39 | ₹3,06,390.00 |
1 × ₹489.79
₹489.79
excl. GST
₹577.95 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NTMFSC4D2N10MC
₹489.79 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 1.67nF
- Ciss-Input Capacitance
- 2.856nF
- Pd - Power Dissipation
- 122W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 100V
- Current - Continuous Drain(Id)
- 116A
- Reverse Transfer Capacitance (Crss)
- 29pF
- RDS(on)
- 12mΩ@6V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 42nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.16 g
Overview
Applications
- Orring FET/Load Switching
- Synchronous Rectifier
- DC−DC Conversion
Key features
- Advanced Dual−Sided Cooled Packaging
- Ultra Low RDS(on) to Minimize Conduction Losses
- MSL1 Robust Packaging Design
- 175 oC TJ Capable
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
